Input Voltage:230VAC
Output Voltage:12VDC
Frequency Range:10Hz to 100kHz
Isolation Voltage:1500V
Operating Temperature:-40°C to +85°C
Board Size:5cm x 7cm
Weight:50g
The A-B SK-20P-S5N07 Pulse Transformer Board is meticulously crafted for applications requiring high-speed pulse isolation. Its design focuses on delivering superior electrical isolation and minimal phase distortion.
This pulse transformer board operates within a wide temperature range from -40°C to +85°C, making it suitable for harsh industrial environments where extreme temperatures are common.
Equipped with a robust insulation material and a high isolation voltage rating of 2500VAC, this board ensures reliable signal transmission without compromising on safety.
The compact size and lightweight construction of the A-B SK-20P-S5N07 facilitate easy integration into existing systems, while its connector type is compatible with industry-standard connectors, simplifying installation.
With its excellent pulse width handling capability of up to 500ns, this pulse transformer board is ideal for applications demanding precise timing and signal integrity.
