Manufacturing Company:ABB
Model:AGDR-72C
Module Type:IGBT
Operating Voltage:400V
Current Rating:72A
Temperature Range:-40°C to +125°C
Package Size:W: 85mm x L: 140mm x H: 42mm
Weight:0.5kg
Insulation Class:B
Cooling Method:Air Cooled
The ABB AGDR-72C IGBT Module is engineered with state-of-the-art semiconductor technology, ensuring superior performance in high-demand industrial environments. It is ideal for applications requiring precise control over electrical power, from renewable energy systems to electric drives.
Designed for efficiency, the module supports peak currents up to 400A and maintains a continuous current of 200A, making it suitable for demanding load requirements. Its high switching frequency of up to 20kHz ensures minimal power loss and improved system responsiveness.
With a focus on safety and reliability, the ABB AGDR-72C comes equipped with an insulation resistance of ≥ 10^9 ohms at 500V DC, exceeding industry standards and guaranteeing exceptional electrical isolation. This feature is crucial for maintaining operational safety and preventing electrical hazards.
In terms of design, the module boasts a compact form factor, optimized for space-saving installations in various industrial settings. The use of thermal convection cooling ensures efficient heat dissipation without the need for external cooling systems, contributing to reduced maintenance costs and enhanced system reliability.
Furthermore, the ABB AGDR-72C IGBT Module is constructed with high-quality materials to withstand harsh environmental conditions, ensuring longevity and minimizing downtime. Its robust design and versatile compatibility make it a preferred choice for integrating into complex power management systems.
