Number of Channels:4
Input Range:-20 to 20 mA
Common Mode Voltage Range:-20 to 20 V
Absolute Input Voltage:+/- 7.5 VDC or 7.5 VAC RMS (Max.)
Voltage Rating:Overvoltage Protection: 7.5 VAC RMS
Input Range for DC Voltage:-10 to 10 VDC – 1 LSB
Current Rating:Backplane Current Draw: 35 MA at 5 V, 85 MA at 24 V
Isolation:Backplane: 500 VDC, Enclosure: Open Type
The Allen Bradley 1746-INT4 Analog Input Module is designed to enhance the precision of industrial automation systems by providing high-resolution signal conversion capabilities. This module offers four channels for analog inputs, each capable of accurately reading a wide range of electrical signals from sensors and other devices.
Equipped with advanced technology, this module ensures reliable operation under varying environmental conditions, making it suitable for use in harsh industrial environments. Its high common mode voltage range and absolute input voltage specifications guarantee robust signal integrity, even in noisy or fluctuating conditions.
Featuring isolation and overvoltage protection, the 1746-INT4 ensures safe and secure operation without affecting other system components. This module can be easily integrated into existing systems, thanks to its compatibility with various communication interfaces and power supply requirements.
Designed for efficiency, the module is optimized for energy consumption, reducing operational costs and enhancing system performance. It is an essential component for applications requiring precise measurement and control, such as temperature monitoring, pressure sensing, and flow rate measurement.
To further support its functionality, the Allen Bradley 1746-INT4 Analog Input Module is accompanied by detailed documentation and technical support services. This ensures seamless integration, easy maintenance, and optimal utilization in diverse industrial settings.
