Manufacturer:Allen Bradley / Rockwell Automation
Model Number:2094-AC05-MP5-S
Type Designation:Servo Drive / Axis Module
Input Voltage Range:195 to 264 Volts AC 3-phase
Input Frequency Range:47 to 63 Hertz
Velocity Loop Frequency:500 Hz
Current Loop Frequency:1300 Hz
PWM Frequency:8 kHz
Rated Efficiency:95%
Capacitance:75 μF
Capacitive Energy Absorption:10 Joules
Internal Shunt Resistor:115 Ohms
Shunt-on Voltage:805 VDC
Shunt-off Voltage:765 VDC
Operating Temperature:-10°C to +60°C
Enclosure Rating:NEMA/UL Type 1, IP 20
The Allen Bradley 2094-AC05-MP5-S Servo Drive is part of the Kinetix 6000 drive series, designed for seamless integration into various industrial control systems. Its advanced control algorithms and high precision capabilities make it perfect for applications that demand exceptional performance and reliability.
With a velocity loop frequency of 500 Hz and a current loop frequency of 1300 Hz, this servo drive ensures smooth and accurate motion control, which is essential in high-speed manufacturing processes.
The PWM frequency of 8 kHz contributes to efficient energy management, minimizing losses and improving overall system efficiency. The drive’s rated efficiency of 95% further underscores its capability to deliver optimal performance with minimal energy consumption.
Equipped with an internal shunt resistor of 115 Ohms, this servo drive provides precise current sensing, critical for maintaining stable operation under varying load conditions. The capacitive energy absorption of 10 Joules enhances the system’s resilience against transient disturbances.
Designed with user-friendliness in mind, the Allen Bradley 2094-AC05-MP5-S Servo Drive supports a wide operating temperature range from -10°C to +60°C, ensuring reliable operation in diverse environmental conditions. Its NEMA/UL Type 1, IP 20 enclosure rating guarantees protection against dust and water ingress.
