Allen-Bradley 2098-DSD-HV220-SE, High-Voltage AC Drive

Operating Voltage:800 Volts DC

Internal Shunt Resistance:20 Ohms

Dimensions:9.54 x 15.43 x 8.0 inches (242.2 x 391.8 x 203.2 mm)

Continuous Output Current:47A

Intermittent Output Current:94A

Continuous Power Output:10.0 kW @ 480 VAC, 5.0 kW @ 230 VAC

Operating Temperature Range:0°C to 55°C

Relative Humidity Range:0% to 95% non-condensing

USB Support:USB 1.0 and 2.0 (communication rates up to 38,400 bps)

    The Allen-Bradley 2098-DSD-HV220-SE AC Drive is a robust, high-performance solution designed to meet the stringent demands of modern industrial automation. Its intelligent design supports contemporary integration and configuration methods, ensuring seamless integration with existing systems.

    With a wide input voltage range and a choice of auxiliary power supply, this drive offers unparalleled flexibility and reliability. It boasts a nominal input current of 14 Amps and a frequency range of 47-63 Hz, making it suitable for a variety of applications.

    Featuring a continuous output power capacity of 10.0 kW at 480 VAC and 5.0 kW at 230 VAC, the 2098-DSD-HV220-SE ensures high efficiency and performance across different operational scenarios. Its advanced indexing feature enhances machine control, delivering superior performance and accuracy.

    Equipped with a 20 Ohm internal shunt resistance, the drive ensures stable operation under varying conditions. It is designed for use within a temperature range of 0°C to 55°C, ensuring reliable performance in diverse industrial environments.

    The Allen-Bradley 2098-DSD-HV220-SE is certified to meet multiple drive standards and adheres to EMC directives, ensuring compliance and reliability. This high-voltage AC drive is a standalone solution for various industrial applications, offering a comprehensive set of power platforms, connectivity options, and functions.
