Allen Bradley AB 1746-OB32E SLC 500 Digital DC Output Module

Model Type:SLC 500

Model Number:1746-OB32E

Output Channels:32

Output Voltage Range:5 – 50 VDC

On-State Voltage Drop:1.2 V

Off-State Output Leakage:1 MA

Load Capacity:1 MA

Current Rating:{“Backplane”:”190 MA”,”Continuous Current Per Output”:”0.25 A at 60°C”,”Continuous Current Per Module”:”8 A at 60°C”}

Isolation:{“Communication Circuits”:”500 VDC”,”Backplane”:”1500 VAC”}

Processor:SLC 500

Enclosure Type:Open Type

Mounting Method:Chassis

Temperature Rating:0 – 60°C

Environmental Conditions:5 – 95% non-condensing relative humidity

The Allen Bradley AB 1746-OB32E SLC 500 Digital DC Output Module is engineered for industrial automation applications, ensuring reliable operation under various environmental conditions.

With its 32 digital DC output channels, this module offers versatile control capabilities for a wide range of applications, from machinery control to process automation.

Featuring advanced isolation technology, it ensures safe and efficient operation by maintaining a high level of separation between signal and power lines, preventing interference and enhancing system reliability.

Equipped with an SLC 500 processor, the module benefits from Allen Bradley’s renowned control and processing capabilities, delivering fast response times and precise control.

The open-type enclosure design facilitates easy installation and maintenance, allowing for quick access to modules without compromising the system’s integrity. This modular approach also enables scalability, making it suitable for both small and large-scale industrial automation projects.

AB 1746-OB32E SLC 500 DC Output Module
