Manufacturer:B&R
Model:X20CP1485-1
Type:PLC Control Module
CPU Processor:Intel x86-based, 100 MHz-compatible
Integrated I/O Processor:Yes
Communication Ports:1x RS232, 1x Ethernet, 1x POWERLINK (V1/V2), 2x USB, 1x X2X Link
Power Consumption:Internal I/O: 0.6 W
Input Voltage Range:24 VDC -15% / +20%
Input Current:Max. 2.2 A
Nominal Output Power:7 W
RAM:32 MB SDRAM
Dimensions:Compact form factor for easy installation
Ambient Air Temperature:0°C to +40°C
Protection Rating:IP20
Compliance Standards:CE, C-Tick, UL, cUL, ClassSIL3/PLe
The B&R X20CP1485-1 is a high-performance CPU module designed for demanding industrial applications. With its Intel x86-based processor running at 100 MHz, this module offers exceptional computing capabilities.
Integrated with a variety of interfaces including Ethernet, POWERLINK, RS232, USB, and X2X Link, it facilitates seamless connectivity and communication across different devices and networks.
It features a compact design with a low power consumption of just 0.6 W, making it energy-efficient and ideal for space-constrained environments.
The module operates within a wide range of ambient air temperatures (0°C to 40°C) and meets protection standards such as IP20 and NEMA 1, ensuring reliable performance in various industrial settings.
With its comprehensive set of status indicators, users can easily monitor the module’s health and operational status.
