Assembly Type:Standardized
Original Manufacturer Location:Domestic
Functional Product Abbreviation:ADGIH
PCB Coating Style:Normal
Grouping:Mark V Series Group One
Significant Product Revision:A
Number of Connectors:{“40-pin”:”1″,”60 Jumpers”:”60″,”6-pin”:”1″}
Test Points:Multiple
Width (inches):8
Length (inches):6
Installation Compatibility:Board Cabinet of Drive
Screws Quantity:4
Screws Alignment:Aligned for secure installation
Weight:0.6 kg
Unveiling a marvel of engineering, the GE DS200ADGIH1AAA Interface Board is meticulously crafted for seamless integration within the Mark V Turbine Control System. This specialized hardware component is designed to elevate operational efficiency and reliability through its robust construction and precise functionality.
Featuring a compact yet powerful design, the DS200ADGIH1AAA Interface Board boasts an impressive array of specifications, including a single 40-pin connector, six jumpers, and a 6-pin connector, ensuring compatibility and ease of use across diverse applications.
Populated with multiple test points, this board guarantees comprehensive diagnostics and maintenance support, facilitating quick troubleshooting and system optimization.
At 8 inches wide and 6 inches long, the DS200ADGIH1AAA is tailored for efficient installation within the board cabinet of the drive, offering a streamlined solution for on-site integration.
Crafted with durability and reliability in mind, the board is equipped with four screws, ensuring secure attachment and a solid foundation for long-term performance within the high-pressure environment of turbine control systems.
