Manufacturer:General Electric
Model:IP-QUADRATURE
Type:Quadrature Encoder
Resolution:1000 lines per revolution
Operating Voltage:10-30 VDC
Frequency Range:Up to 10 kHz
Output Signal:Push-pull or open collector
Protection Rating:IP65
Mounting Style:Hub/shaft mounting
Output Channels:A, B, Z, Index
Environmental Operating Temperature:-20°C to +85°C
Mechanical Life:Over 50 million pulses
The GE IP-QUADRATURE encoder is engineered to deliver exceptional precision and durability in harsh industrial environments. With a resolution of 1024 PPR, it provides accurate feedback for precise motion control systems.
This encoder is built to withstand demanding conditions, featuring an IP67 protection rating which ensures it remains impervious to dust and water ingress. The operating temperature range of -20°C to +85°C makes it suitable for both indoor and outdoor applications.
Equipped with a 5V DC operating voltage, the GE IP-QUADRATURE operates reliably across a wide range of industrial power supplies. Its quadrature A/B phase and index Z phase outputs provide robust and reliable position data.
The encoder’s compact size and hub coupling mounting style make it easy to integrate into existing machinery or new installations without requiring significant space or specialized tools.
Backed by GE‘s commitment to quality and innovation, the IP-QUADRATURE is a dependable solution for any industrial automation project that requires precise and reliable motion control.
