Brand:GE
Model:SR750-P5-G1-S1-HI-A20-R
Place of Origin:SR750-P5-G1-S1-HI-A20-R
Order Number:SR750-P5-G1-S1-HI-A20-R
Custom Processing:Yes
Item No.:SR750-P5-G1-S1-HI-A20-R
Series:SR750-P5-G1-S1-HI-A20-R
Material Coding:SR750-P5-G1-S1-HI-A20-R
Communications Baud Rate:300 to 19200 baud
Frequency:25 to 60 Hz nominal
Operating Environment Humidity:Up to 90% non-condensing
Overvoltage Pickup Level:0 to 1.25 × VT in steps of 0.01
Relay Dimensions:Approx. 18cm W, 16.5cm L, 21.5cm H
Waveform Capture Channels:4 currents, 3 voltages, 14 logic input states, 8 output relays
Certified Product:SR750-P5-G1-S1-HI-A20-R
Output Frequency:50 kHz
Operating Voltage:220 V
The GE SR750-P5-G1-S1-HI-A20-R is an advanced feeder management relay designed to provide reliable control and protection for distribution systems. This relay boasts multiple current and voltage channels, enabling comprehensive waveform capture and analysis. Its modular design allows for flexible installation, either individually or alongside other GE 750 series units. The device supports communication protocols like Modbus RTU and DNP 3.0, making it easy to integrate into existing systems. With features such as overcurrent protection, under/overfrequency protection, and ground fault protection, this relay ensures robust performance and safety. The relay is built to withstand harsh operating environments, with humidity tolerance up to 90% non-condensing. Its compact dimensions make it suitable for panel mounting in various settings.
