Connector Type:High-Speed Data Connector
Pin Count:24 pins
Voltage Rating:250V AC
Current Rating:1A per pin
Operating Temperature Range:-40°C to +105°C
Contact Material:Gold-plated copper alloy
Shell Material:Thermoplastic UL94 V-0
Insert Retention Force:10N minimum
Durability:1000 mating cycles
The MOLEX 85003-0567 Industrial Connector Module is meticulously designed for demanding industrial environments. Its rugged construction and high-performance specifications make it an ideal choice for automation systems and manufacturing processes where reliability and durability are paramount. Key design highlights include a robust RJ45 connector with 8-pin configuration, capable of handling up to 250V and 1A of current. The module is fully RoHS compliant and rated for operation within a temperature range of -40°C to 85°C, ensuring consistent performance under extreme conditions. The IP67 rating provides protection against dust ingress and water immersion, making it suitable for outdoor installations and environments with high levels of particulate matter. Additionally, the module features advanced shielding to minimize electromagnetic interference, ensuring stable and reliable data transmission. With a data rate of 1 Gbps, the MOLEX 85003-0567 is perfectly suited for modern industrial communication networks, offering fast and efficient data transfer. Installation is straightforward with a 1-meter cable included, allowing for easy integration into existing infrastructure. This connector module is a testament to MOLEX’s commitment to delivering high-quality, reliable components for industrial applications.
