Number of Channels:16
Rating per Channel:5A SPST
Operating Voltage:12VDC
Operating Current:1A
Relay Contact Rating:5A @ 24VDC, 3A @ 115VAC
Relay Type:SPST
Module Size:Compact 3U PXI form factor
Communication Interface:PXI Bus
Power Consumption:≤ 2W
Temperature Range:-40°C to +85°C
Relay Life Expectancy:Over 100 million operations
Integrating seamlessly into PXI systems, the NI PXI-2564 Relay Module offers unparalleled reliability and durability, making it ideal for complex test and measurement applications where precision and efficiency are paramount.
Each channel is equipped with a SPST contact rated for continuous operation at up to 5A, ensuring robust performance even under heavy-duty conditions. The module supports a wide range of operating voltages from 12 to 48V DC, providing flexibility for various industrial setups.
With an operational temperature range of -20°C to +70°C, the PXI-2564 is designed to withstand harsh environmental conditions without compromising on performance. Its impressive relay life of over 100 million cycles guarantees long-lasting reliability in critical applications.
Featuring a compact and lightweight design, the PXI-2564 is easy to integrate into existing PXI chassis, minimizing space requirements and simplifying system integration. The panel mount style ensures secure installation, enhancing the overall system stability.
Backed by National Instruments’ commitment to innovation and quality, the PXI-2564 Relay Module is supported by comprehensive documentation and a suite of software tools, enabling users to optimize their test systems and streamline workflow.
