Signal Range:Pt100Ω (JIS, IEC), JPt100Ω
Current Consumption:0.18 to 0.06A
Conversion Speed:250ms/8 inputs
Number of Inputs:4
Input Type:Analog
Dimensions (HxWxD):90 x 86 x 50mm
Module Type:DIN Rail
Operating Voltage:24VDC (20.4 to 28.8VDC)
Leakage Current:0.1mA max.
Output Type:Thermocouple
Contact Resistance:Max. 50mΩ
Introducing the OMRON CP1W-TS002, a state-of-the-art analog input module that stands at the forefront of industrial automation technology. This module boasts an impressive array of features tailored for the most demanding control applications, ensuring optimal performance in various industrial settings.
Featuring 4 high-precision input ports capable of handling signals from Pt100 platinum resistors, the CP1W-TS002 ensures exceptional measurement accuracy, making it ideal for critical temperature monitoring and control tasks.
With its robust design, the CP1W-TS002 can withstand harsh industrial environments, providing reliable operation over a wide range of temperatures. Its compact size and DIN rail mounting capability make it highly adaptable to different installation scenarios.
The inclusion of a 250 ms conversion speed per 8 inputs ensures swift data processing, enabling real-time response and enhanced operational efficiency. This feature is particularly advantageous in fast-paced automation systems where quick decision-making is crucial.
Moreover, the module is equipped with a maximum leakage current of 0.1 mA, which minimizes power consumption and reduces the risk of system errors due to leakage currents. This ensures stable operation and increased reliability in long-term use.
Experience the future of industrial control with the OMRON CP1W-TS002. This cutting-edge analog input module is your gateway to achieving higher productivity, enhanced safety, and superior quality control in your manufacturing processes.
