OMRON E6H-CWZ3X Hollow Shaft Line Driver Codificador: High Precision Encoder for Industrial Automation

Model Number:E6H-CWZ3X

Shaft Diameter:Hollow Shaft

Resolution:1024 P/R

Operating Voltage:5 to 24 VDC

Output Type:Open Collector

Rotation Speed:Up to 1000 RPM

Environmental Temperature Range:-20°C to +70°C

Communication Interface:RS-485

Enclosure Type:IP67 Rated

Weight:Approximately 200g

    The OMRON E6H-CWZ3X Hollow Shaft Line Driver Encoder is designed for high-precision motion control applications. Its incremental encoding method provides accurate angular feedback, ensuring smooth operation and precise positioning.

    Featuring a compact hollow shaft design, this encoder is suitable for integration into a variety of machinery where space is limited. It ensures reliable performance even in challenging industrial environments.

    With its robust construction and wide operating temperature range, the E6H-CWZ3X is engineered to withstand harsh conditions typically encountered in manufacturing processes. This makes it an ideal choice for applications requiring high durability and reliability.

    The encoder’s NPN open collector output phase supports simple connection to various control systems, reducing setup time and complexity. The 1-meter cable length ensures flexibility in installation while minimizing signal degradation.

    Innovative design elements include advanced noise reduction technology, which enhances signal integrity and minimizes interference, leading to improved overall system performance. Additionally, the OMRON E6H-CWZ3X is compatible with a wide range of control modules, facilitating seamless integration into existing automation systems.
