Frequency Range:up to 1 GHz
Waveform Types:Sine, Square, Triangle, Ramp, Pulse, Arbitrary
Amplitude:20 Vpp into 50 Ohms
Frequency Resolution:1 μHz
Output Impedance:50 Ohms
DC Offset:+/-10 V
Harmonic Distortion:<0.05% at 1 kHz
Phase Shift:0 to 360 degrees
Built-in Functions:Arbitrary waveform generation, frequency sweep, amplitude modulation
The Tektronix 5A48 Arbitrary Function Generator is designed for professionals who require high-performance signal generation capabilities. It provides a comprehensive set of waveform types and can generate signals with up to 20 MHz frequencies, making it suitable for a variety of demanding applications.
This model features a 14-bit resolution for precise control over signal amplitude and shape, ensuring that users can achieve highly accurate results in their experiments and tests. The device also supports external, internal, manual, and line trigger modes, providing flexibility in signal generation.
The generator comes with a memory depth of 16 kpts, allowing users to store and recall complex waveforms with ease. Its robust design ensures reliable performance in laboratory and industrial settings, making it an indispensable tool for researchers and engineers.
The compact design of the Tektronix 5A48 makes it easy to integrate into existing setups without taking up too much space. Its user-friendly interface simplifies operation and maintenance, reducing downtime and increasing productivity.
With multiple waveform types, high-frequency capabilities, and precise control options, the Tektronix 5A48 Arbitrary Function Generator is an essential instrument for anyone involved in signal generation and analysis.
